Cảm biến áp suất Dynisco PT4624-50MPA-6/18-A
Cảm biến áp suất Dynisco PT4624-50MPA-6/18-A thuộc PT46X4 series sử dụng để đo cảm biến áp suất nóng chảy (Melt pressure sensor) hay còn gọi bộ chuyển đổi áp suất nóng chảy (Melt Pressure Transmitters) với tín hiệu khuếch đại 4-20 mA. Cảm biến mA của Dòng PT46X4 có thể được đặt lại về 0 theo hai cách: tại chỗ thông qua biến trở về 0 hoặc từ xa thông qua việc nối tắt hai chân với nhau (đóng tiếp điểm). Có option tùy chọn nhiệt điện trở hoặc RTD để sử dụng đo nhiệt độ nóng chảy. Có ren UNF 1/2-20 để lắp đặt đơn giản và dễ dàng vào các lỗ lắp đầu dò tiêu chuẩn.
The PT46X4 Series pressure sensor is a ±0.5% sensor ideal for general melt pressure measurements requiring simple installation, repeatability and reliability.
The PT46X4 features a 1/2-20 UNF thread for simple and easy installation in standard transducer mounting holes. The 4-20 mA output signal is rated PL‘c’ as described in the Machinery Directive EN ISO 13849-1.
The PT46X4 Series mA sensors are self-certified based on the evaluation reports of the respected third-party agency, exida™. The PT46X4 Series mA sensors have undergone extensive FMEDA analysis (Failure Mode Effects and Diagnostic Analysis). The FMEDA reports show that these sensors have been evaluated for random failure requirements and meet Performance Level ‘c’ (PL‘c’) as well as SIL2 (Safety Integrity Level 2). The information in the FMEDA report can be used by the customer’s system designer as part of the overall qualification of the device in the system for PL‘c’ or SIL compliance.
The PT46X4 Series can be equipped with a safety relay, separate from the signal output. Called Guardian, this optional relay signal has an application specific pressure threshold setting that will place a machine in a safe mode as described in the Machinery Directive EN ISO 13849-1.
Thông số Dynisco PT4624-50MPA-6/18-A pressure sensor
- Output: 4-20 mA
- Input Voltage: 14-36 Vdc
- Accuracy: ±0.5% FSO combined error (Including Linearity, Repeatability & Hysteresis)
- Repeatability: ±0.2% FSO
- Configuration: Four-arm bonded foil Wheatstone bridge strain gage
- Load Resistance: 0-1,100 Ohms
- Over Pressure: 2x FSO or 35,000 psi (whichever is less)
- Internal Shunt Calibration (R-Cal): 80% FSO ±0.5%
- Insulation Resistance: 1,000MΩ @ 50 Vdc
- Diaphragm Temp, Max: 750°F (400°C)
- Zero Shift (temp chg): 25 psi/100°F Typical (45 psi/100°C)
- Electronics Operating Temp: -20° to 185°F (-29° to 85°C)
- Zero Shift (temp chg): ±0.05% FS/°F max (±0.10% FS/°C max
- Mounting Torque: 500 inch/lbs. max
- Standard Wetted Parts: DyMax® coated 15-5 PH SST
- SIL2 : Safety Integrity Level 2
Qúy công ty cần báo giá, catalogue, datasheet, manual cảm biến áp lực Dynisco PT4624-50MPA-6/18-A Melt Pressure Transmitters vui lòng liên hệ với chúng tôi theo thông tin sau:
PHÒNG KINH DOANH – CÔNG TY TNHH EURODODO
Địa chỉ: 6/33/7/4 Đường Vườn Lài P. An Phú Đông Q.12 TP.HCM
Website: EuroDodo.com
Email: kinhdoanh@eurododo.com
Email dự phòng: eurododo.coltd@gmail.com
Hotline: 03-7400-8015 (zalo)
